What is Pit-Stack G-1 Parking System?

The Pit-Stack G-1 Parking System is a reliable and economical solution that maximizes parking capacity. It is ideal for residential societies, commercial complexes, and real estate developments.

How much space is required for installation?

Our systems are designed to be space-efficient, requiring minimal headroom and ground space, making it a versatile choice for basements, podiums, and open spaces.

Is the system safe for heavy vehicles like SUVs?

Yes, our parking systems are built with heavy-duty structural steel and advanced locking mechanisms to safely secure SUVs and sedans.

Do you provide installation services PAN India?

Absolutely. Honesty Parking provides complete end-to-end manufacturing, installation, and maintenance services for parking systems across New Delhi, Mumbai, Pune, Bangalore, Hyderabad, and all over India.

Independent Parking

Pit-Stack G-1 Parking System

The Pit-Stack G-1 Parking System is an advanced underground parking solution designed to maximize parking capacity while maintaining independent vehicle access. The system features a single hydraulic lifting platform installed within a specially designed pit below ground level. When a vehicle needs to be parked or retrieved, the platform smoothly lifts or lowers using a precision-engineered hydraulic mechanism, ensuring safe, reliable, and effortless operation.

Safe & Reliable

Engineered for safety
and long term use

Easy Operation

Smooth hydraulic
& mechanical system

Built to Last

Premium components
& high durability

Space Efficient

Double parking in
the same footprint

Pit-Stack G-1 Parking System

Underground Parking Solution for Smarter Space Management

Our Single Pit Parking System is engineered to provide a compact, secure, and space-saving parking solution for modern infrastructure. Built with a high-strength steel platform and advanced hydraulic lifting technology, it delivers smooth vehicle movement, reliable operation, and enhanced safety.

⚡ Fast Operation

🛡️ Safety First

🔧 Low Maintenance

✅ 2500 Kg Capacity

Specifications

Comprehensive dimensional requirements, electrical specifications and structural guidelines are available in the product brochure.

Pit-Stack G-1 Parking Independent

MODEL		Small Size Car	SUV's
Machine Specification	Platform Length (mm)	4800 to 5000	4500 to 5000
	Platform Width (mm)	2300 to 2500	2300 to 2550
	Lifting Capacity per Platform (Kg)	2000Kg	2000
	Lifting Clearance	1700 to 1800	1800 to 2000
	Lifting Operation	Hydraulic & Electromechanical	Hydraulically & Electromechanical
	Motor on Power Pack	2.2KW/5HP	2.2KW/5HP
	Operating Panel	Automatic / Manual	Automatic / Manual

For more details Download Brochure

Download Brochure

Standard Features

Space & Design

Independent underground parking platform.
Space-saving pit installation.
Two platforms per system.
Compact design for residential and commercial projects.
One platforms on ground & one in pit.
Color scheme for the system can be provided as per the client's requirement.

Operation & Safety

Optional photo sensor for the middle car to prevent accidental lowering of upper stack or lifting of the lower stack.
Electromagnetic locking mechanism to prevent unwanted lowering of upper stacks.
Limit switches to restrict the travel height by auto cutting off the motor.
Emergency shutdown switch.

Build Quality

Hot dipped galvanized corrugated floor plates on platforms to reduce dead weight and increase durability.
Hydraulic cylinders & chain supported balancing used for lifting mechanism
Compact power pack system with enclosed motor and rubber bush fittings for reduced noise levels.
